Specifications
Scroll tables horizontally to view every column.
| Model information | |
| Production years | 1963 - 1967 |
| Equipment type | Row-Crop tractor |
| Production | |
| Manufacturer | Farmall (a part of International Harvester) |
| Equipment type | Row-Crop tractor |
| Built in | Built in Rock Island, Illinois, USA |
| Total built | 45,053 |
| Original price | Original price was $6,100 in 1967 |
| Notes | The 706 was available with a new Torque Amplifier design that prevented free-wheeling when going downhill. An over-center hand clutch was an option, usually found on Wheatland (standard tread) models. The 706 was available with either the Fast Hitch or a standard 3-point hitch. The PTO featured both 540 and 1000 RPM shafts, both of which turned while in use. |
| Variants | |
| Farmall 706 | row-crop |
| IH 706 | standard-tread |
| IH 2706 | industrial |
| 706 Hi-Clear | high-crop |
| Farmall 706 Engines | |
| Engine | International Harvester 4.6L 6-cyl diesel International Harvester 5.1L 6-cyl diesel International Harvester 4.3L 6-cyl gasoline Interntional Harvester 4.8L 6-cyl gasoline |
| Details | Engine details ... |
| Farmall 706 Transmissions | |
| Transmission | 8-speed 16-speed |
| Details | Transmission details ... |
| Farmall 706 Power | |
| Engine (gross) | 89 hp 66.4 kW |
| Drawbar (claimed) | 65 hp 48.5 kW |
| PTO (claimed) | 73.5 hp 54.8 kW |
| Drawbar (tested) | 67.46 hp 50.3 kW |
| PTO (tested) | 76.56 hp 57.1 kW |
| Details | Performance test details ... |
| Mechanical | |
| Drive | Two- or four-wheel drive |
| Steering | Power steering |
| Brakes | Hydraulic dry double disc brakes |
| Cab / ROPS | Cab optional, A/C available starting in 1966 |
| Capacity | |
| Fuel | 33 gal (gas/diesel) 124.9 L 39 gal (LP gas) 147.6 L |
| Hydraulic system | 17 gal 64.3 L |
| Hydraulics | |
| Type | open center |
| Capacity | 17 gal 64.3 L |
| Valves | 1 or 2 |
| Pump flow | 12 gpm 45.4 lpm 17 gpm (optional) 64.3 lpm 3 gpm (PTO pump) 11.4 lpm |
| Steering flow | 9 gpm 34.1 lpm |
| Tractor hitch | |
| Rear Type | 2 |
| Type | IH Fast Hitch |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000
1000
|
| Engine RPM | 540@2100
1000@2100
|
| Dimensions & Tires | |
| 2WD Wheelbase | 97.5 inches 247 cm |
| 4WD Wheelbase | 94.75 inches 240 cm |
| Weight | 7530 to 9160 pounds |
| Front tire | 6.50-16 |
| Rear tire | 15.5-38 |
| Details | Full dimensions and tires ... |
| Farmall 706 attachments | |
| Attachment | front-end loader |
| Details | Attachment details ... |
| 706 Serial Number Location | |
| Location | Serial number plate on the left side of the 706 clutch housing. |
| 706 Serial Numbers | |
| 1963 | 501 |
| 1964 | 7073 |
| 1965 | 21162 |
| 1966 | 30288 |
| 1967 | 38521 |
| Final | 46647 |
| Details | FAQ: How to read a serial number table. |
| Belt Pulley | |
| Diameter | 11 inches 27 cm |
| Width | 7.5 inches 19 cm |
| RPM | 1055 |
| Speed | 3,038 ft/min 925.98 meters/min |
| Electrical | |
| Ground | negative |
| Charging amps | 25 (generator)
32 (alternator)
|
| Batteries | 1 (gas)
2 (diesel)
|
| Battery volts | 12 (gas)
6 (diesel)
|
| Battery AH | 60 (gas/LP)
130 (diesel)
|
| References | |
| Publication | Farm Loaders published in 1965, by International Harvester Farm Loaders published in 1970, by International Harvester 706 - 806 Farmall Tractors published by International Harvester New McCormick Farmall 706 Tractor published in 1963, by International Harvester Operator's Manual McCormick Farmall and International 706 Tractors (1014498R3) published in 1965 |
Values may vary by engine, transmission or configuration. View source page
