Specifications
Scroll tables horizontally to view every column.
| Model information | |
| Production years | 1963 - 1974 |
| Series | 100 Series |
| Equipment type | Garden tractor |
| Production | |
| Manufacturer | John Deere |
| Equipment type | Garden tractor |
| Built in | Built in Horicon, Wisconsin, USA |
| Notes | The "10" in the John Deere 110 model name did not refer to the tractor's horsepower, but was keeping in line with the New Generation tractor models (1010, 2010, 3010, 4010). |
| Variants | |
| 110H | hydraulic lift |
| John Deere 110 Engines | |
| Engine | 7HP Kohler 277cc 1-cyl gasoline 8HP Kohler 305cc 1-cyl gasoline |
| Fuel tank | 1.9 gal 7.2 L |
| Details | Engine details ... |
| John Deere 110 Transmissions | |
| Transmission | 3-speed gear with mechanical CVT 4-speed gear with mechanical CVT |
| Details | Transmission details ... |
| Mechanical | |
| Drive | Two-wheel drive |
| Steering | Manual steering |
| Brakes | Manual brakes |
| Cab / ROPS | Open operator station. |
| Tractor hitch | |
| Type | sleeve hitch (optional) |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual idler pulley |
| Dimensions & Tires | |
| Wheelbase | 44 inches 111 cm |
| Weight | 502 lbs 227 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 8-12 |
| Details | Full dimensions and tires ... |
| John Deere 110 attachments | |
| Attachment | 38" mid-mount mower deck snowblower blade front-end loader |
| Details | Attachment details ... |
| 110 Serial Number Location | |
| Location | Serial number plate below the steering column on the Deere 110. |
| 110 Serial Numbers | |
| 1963 | 2550 |
| 1964 | 3551 |
| 1965 | 15001 |
| 1966 | 40001 |
| 1967 | 65001 |
| 1968 | 100001 |
| 1969 | 130001 |
| 1970 | 160000 |
| 1971 | 185001 |
| 1972 | 250001 |
| 1973 | 272001 |
| 1974 | 310001 |
| Details | FAQ: How to read a serial number table. |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 24 |
| References | |
| Publication | The John Deere 10 Series New Generation Tractors published in 2004, by Hain Publishing America's Leading Farm Equipment Manufacturer Introduces... published in 1963, by John Deere 110 Lawn and Garden Tractor published in 1964, by John Deere 110 Lawn and Garden Tractor published in 1965, by John Deere Weekend Freedom Machine published in 1966, by John Deere Add a handyman to your staff... published in 1966, by John Deere John Deere Lawn & Garden Tractors published in 1967 Modern Farming published in 1965, by John Deere Work Horse Loader for 110 Lawn & Garden Tractor published in 1965, by Johnson Operator's Manual 110 (OM-M40401) published in 1963 Operator's Manual 110 and 110H (OM-M41412) published in 1966 Service Manual 110 and 112 Lawn and Garden Tractors (SM-2059) published in 1967 Operator's Manual 38 Rotary Mower (OMM41126) published in 1963 Operator's Manual 42 Front Blade (OMM440688) published in 1963 |
Values may vary by engine, transmission or configuration. View source page
Model family
Series map
- 110 Current model7.0 hp
- 11210.0 hp
