Attachments
Scroll tables horizontally to view every column.
| Attachment overview | |
| Attachment | 38" mid-mount mower deck 46" mid-mount mower deck Snowblower Blade Front-end loader |
| Width | The 140 was compatible with the model 33 tiller with 26-, 34-, or 42-inch width. |
| 38" Mower deck | |
| Attachment model | John Deere 41 |
| Notes | 38 inches 96 cm |
| Width | Total width: 49.25 inches 125 cm |
| Blades | 3-blade |
| Lift | hydraulic lift |
| Notes | right-discharge |
| Height | Cut height: 1.5 to 3.5 inch 3 to 8 cm |
| Notes | 111 lbs 50 kg 46" Mower deck John Deere 48 46 inches 116 cm |
| Width | Total width: 57 inches 144 cm |
| Blades | 3-blade |
| Lift | hydraulic lift |
| Notes | right-discharge |
| Height | Cut height: 1.5 to 3.5 inch 3 to 8 cm |
| Notes | 144 lbs 65 kg |
| 54" Blade | |
| Attachment model | John Deere 54 |
| Mounting | front-mount |
| Width | 54 inches width 137 cm |
| Height | 18 inches height 45 cm |
| Lift | 15 inches lift 38 cm |
| Notes | Angling 30° 3.5 inches cut 8 cm 140 lbs 63 kg |
| Lift | hydraulic-lift |
| Angle adjustment | manual-angle |
| Notes | 54" Blade John Deere 54C center-mount |
| Width | 54 inches width 137 cm |
| Lift | 3 inches lift 7 cm |
| Notes | Angling 20° 0.75 inches cut 1 cm 104 lbs (manual) 47 kg 112 lbs (hydraulic) 50 kg |
| Lift | hydraulic-lift |
| Angle adjustment | manual-angle hydraulic -angle (optional) |
| 46" Snow blower | |
| Attachment model | John Deere 49 |
| Width | 46 inches width 116 cm |
| Notes | one-stage |
| Mounting | front-mount |
| Lift | hydraulic-lift |
| Notes | 197 lbs 89 kg |
| Johnson 12 Loader | |
| Lift capacity (full at pin) | 500 lbs lift (full at pin) 226 kg |
| Notes | 47° dump 16 inches reach (dumped) 40 cm |
| Height | 69.5 inches height (at pin) 176 cm |
| Dump clearance | 54 inches clearance (dumped) 137 cm |
| Notes | 67 inches clearance (level) 170 cm |
| Weight | weight: 410 lbs 185 kg |
| Bucket width | Bucket width: 38 inches 96 cm Bucket width: 48 inches 121 cm |
Values may vary by engine, transmission or configuration. View source page
