Specifications
Scroll tables horizontally to view every column.
| Model information | |
| Production years | 2022 - |
| Series | SA Series |
| Equipment type | Compact Utility tractor |
| Production | |
| Manufacturer | Yanmar |
| Equipment type | Compact Utility tractor |
| Yanmar SA425 Engine | |
| Engine | Yanmar 1.3L 3-cyl diesel |
| Fuel tank | 6.1 gal 23.1 L |
| Details | Engine details ... |
| Yanmar SA425 Transmission | |
| Transmission | hydrostatic |
| Details | Transmission details ... |
| Yanmar SA425 Power | |
| Engine (gross) | 23.9 hp 17.8 kW |
| Engine (net) | 21.7 hp 16.2 kW |
| PTO (claimed) | 18.1 hp 13.5 kW |
| Mechanical | |
| Drive | Four-wheel drive |
| Differential lock | mechanical rear |
| Steering | Power steering |
| Brakes | Wet disc brakes |
| Cab / ROPS | Two-post folding ROPS. Four-post ROPS canopy available (425HDX). |
| Hydraulics | |
| Type | open center |
| Pressure | 2429 psi 167.5 bar |
| Pump flow | 4.3 gpm 16.3 lpm |
| Steering flow | 3.7 gpm 14.0 lpm |
| Tractor hitch | |
| Rear Type | I (Limited) |
| Control | position control |
| Rear lift (at 24"/610mm) | 1209 lbs 548 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 554@3200 |
| Mid PTO | independent |
| Mid PTO Type | 16/32 15T |
| Engine RPM | 2057@3200 |
| Dimensions & Tires | |
| Wheelbase | 63 inches 160 cm |
| Weight | 1830 lbs 830 kg |
| Details | Full dimensions and tires ... |
| Yanmar SA425 attachments | |
| Attachment | 60" mid-mount mower deck front-end loader backhoe |
| Details | Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 40 |
| Battery CCA | 540 |
| Battery volts | 12 |
| References | |
| Publication | SA223/325/425 published in 2022, by Yanmar 425 Multi-Purpose Compact Tractor published in 2022, by Yanmar* |
| Publication caveat | *Publication contains known errors. |
Values may vary by engine, transmission or configuration. View source page
